Items needed to complete Larus 2.4

  • 1.5mm Balsasheets
  • 2mm Balsasheets
  • 2.5mm Balsasheets
  • 5mm Balsasheet
  • 2.5mm Plywood Birch
  • 1.5mm Aircraft Plywood
  • 3 Pcs Carbon Tube 12mm x 10mm
  • 1 Pcs Carbon Tube 10mm x 8mm
  • 1 Pcs Carbon Tube 8mm x 6mm
  • 1 Pcs Carbon Tube 6mm x 4mm
  • 2 Pcs Carbon Tube 5mm x 4mm
  • 3000mm of 2mm Coarbon Rod
  • Alu Tube or Brass Tube 7mm x 6.1mm
  • Carbon Rod 6mm
  • 2 Nylonscrews M4
  • 2 Notches M4
  • Bowdencables
  • Oracover Coverfoil
  • 2x Servos (PTK VOTIK 9497 MG-D Micro Digital Servo)
  • 4x Servos (PTK VOTIK 8525MG-D or equal)
  • 2s Lipo 900mah - 1300mah
  • Reciever
  • and Glue of course...etc.

Download Files here:


Contact me:

Having a Question, a Suggestion or Issues?
Drop me a Mail or contact me on facebook.
Please send me Photos of your Alcedo if you build one, so i can set up a little Gallery.
